Viewing Head
Seidentopf Binocular Viewing Head at 30°IncIined Interpupillary (55-75mm)

Eyepiece
Wide Field eyepiece WF10X18mm

Nosepiece
Quadruple Nosepiece
Objective    Achromatic Objective 4X,10X,40X,100X

Stage
Double Layers Mechanical Stage 140X135mm/ 75X50mm

Condense
    Abbe NA1.2５ with Iris Diaphragm & Filter

Focusing System
    Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 28mm

Illumination
S-LED Illumination, Brightness Adjustable
Halogen Lamp 100V-240V/ 6V20W
Plan-concave Mirror

Filter
    White Filter
